Hammerhead Valve Kit, Intake and Exhaust Valve Kit for 150cc, GY6 - M150-1001301-7-Kit

M150-1001301-7-Kit, GY6 150cc Valve Rebuild Kit
$49.99
Availability: In stock
SKU
164-295_hhpPS

Frequently bought together

  1. Hammerhead Valve Kit, Intake and Exhaust Valve Kit for 150cc, GY6 - M150-1001301-7-Kit
  2. +
  3. Hammerhead Bolt, M8x40 Stud Bolt for 250cc Exhaust, Muffler -172MM-022007
  4. +
  5. Hammerhead Bolt, M6x50 Intake Stud for 150cc, GY6 - M150-1001006 replaces 152.11.202, 14264, 3050052
  6. +
  7. Hammerhead Bolt, M6x18 Exhaust Stud / Bolt for 150cc, GY6 - M150-1001011 replaces 152.11.201, 14263
  8. +
  9. Hammerhead Intake Valve Kit for 150cc, GY6 - M150-1001301-N-Kit
  10. +
  11. Hammerhead Exhaust Valve Kit for 150cc, GY6 - M150-1001307-N-KIT
  12. +
  13. Hammerhead Bolt, M8x187.5 Stud Bolt for 150cc, GY6 - M150-1003001 replaces 152.11.203, 14292
  14. +
  15. Hammerhead Bolt, M8x195.5 Stud Bolt for 150cc, GY6 - M150-1003002 replaces 152.11.204, 14291
  16. +
  17. HammerHead Nicasil Cylinder Big Bore Kit 58.5mm (155-160cc) for GY6, 150cc - EG‐GY6‐C585
  18. +
  19. Hammerhead Cylinder Head Assembly with Valves for 150cc, GY6 - M150-100-1320-C replaces, 157.04.200-C, 14254, 513-1000, 3050045-COMP
Total price: $0.00

Thumbnail Name Price Options
$49.99
$2.99
$1.99
$1.49
$29.99
$29.99
$2.99
$2.99
$139.99
$109.99
Total Selected Items:
Total price: $0.00

Valve Assembly for 150cc GY6 4-stroke 150cc engines. Includes intake and exhaust valves, inner and outer springs, valve shims, valve seals, valve keepers, and valve retainers.

150cc Valve Rebuild Kit includes:
(1) M150-1001301-N Intake Valve
(1) M150-1001307-N Exhaust Valve
(2) M150-1001310 Valve Stem Seal
(2) M150-1001302 Valve Spring Seat
(2) M150-1001303 Valve Spring Inner & Outer
(2) M150-1001305 Valve Spring Retainer
(2) M150-1001306 Valve Retainer Clip Set (2 each)

Valve Length (intake & exhaust): 66mm
Shaft Diameter (intake & exhaust): 5mm
Intake Valve Diameter: 27.75mm
Exhaust Valve Diameter: 23mm

Baja Part # BR150S-362, BR150S-363, BR150S-364, BR150S-365, BR150S-366, BR150S-367, BR150S-368
Baja Part # DN150-242, DN150-255, DN150-256, DN150-257, DN150-258, DN150-259, DN150-260, DN150-261
Carter Bros Part # 513-109, 513-1010, 557-1000, 557-1001, 557-1002, 513-1011, 513-1012

DongFang Part # 1.20.01.01.07000, 1.20.01.06.06000, 1.20.01.01.14000, 1.20.01.01.10000, 1.20.01.06.09000, 1.20.01.06.08000, 1.20.01.01.05000, 1.20.01.01.07000


Joyner Part # GY150-303-16-0018, GY150-303-16-0019, GY150-303-16-0020, GY150-303-16-0021, GY150-303-16-0022, GY150-303-16-0023, GY150-303-16-0024


American Landmaster Part # 14267, 14268, 14269, 14270, 14271, 14272, 14273

Tomberlin Part # GK05852, GK05839, GK05854, 1010500, GK05857, GK05858, GK05853
TrailMaster Part # 157.02.301, 152.12.104, 152.02.306, 152.02.303-304, 152.02.305, 152.02.307, 157.02.302
